Closed System Water Testing

To keep on top of closed system treatment and ensure a good balance of chemistry it is important to frequently test your closed system water and make adjustments to chemical dosing and system concentration.

Feedwater can supply all the equipment & testing supplies you require to monitor closed circuit system, we can also provide sample kits so you can send us your system sample to analyse in our chemistry lab.

What We Supply

  • Photometers & Tablets
  • Comparator Disc Sets & Tablets
  • Dropper Titrants & Reagents
  • Testing Meters
  • Sample Kits – Return to lab for analysis

Typical Closed System Testing:

  • pH
  • M. Alkalinity
  • TDS
  • Nitrite, Tannin or Molybdate
  • Phosphate
  • Glycol % (for chiller systems)
  • Iron
  • Aluminium
  • Copper
  • Ammonia (if considered an issue)

If you need advice about what to test for or the control limits to set for your boiler perhaps arrange for a visit by one of our regional consultants, they can advise on efficient operation, recommended chemical treatment and what to measure to keep on top of boiler chemistry.

Photometer Supplies

A Photometer is a device that reads chemical levels by passing light through a cuvette filled with the sample liquid and a crushed reagent tablet. The reaction between the tablet and the chemical present in the water change the colour of the water, the level of the chemical in the water usually determine the strength of the reaction colour.

You start using a ‘blank’ (cuvette with unreacted sample) measuring this the photometer sets a baseline for the water clarity, secondly, you enter the reaction cuvette and will receive a measurement of that specific chemical level.

Comparator Supplies

Contour colour comparators are similar to Photometers except they rely on a visual comparison using a colour disc to match the colour strength and determine the chemical level. In the same way, they use crushable tablets which react with the chemical in the sample being measured.

The Comparator kit is a more cost-effective option to the Photometer especially if you only need a couple of different comparators. Each comparator kit includes an instrument with chemical-specific petal disc, cuvettes, tablet crushers, brush and a batch of tablets. Once the tablets have been used up refills can be orderded.

Titrants & Reagents – Dropper Test Kits

The bulk of your boiler analysis will be performed using dropper titrants which usually involves an indicator (in liquid or tablet form) which colours the sample and then a titrant which will gradually react with the sample until it changes to a new colour. Counting the drops you can then calculate the chemical level in the sample.

This section includes:

  • Dropper Kits
  • Universal pH Strips

We can supply laminated instruction sheets with our dropper test kits and some products will have demonstration videos you can view to get an idea of how it works on the product pages.

Other Products

For measuring TDS you will require a TDS meter, we also offer the service of analysing your closed system water in our chemistry lab, you can order a sampling kit below and be sent out a bottle to fill and return free post.

Full BSRIA Closed System Water Analysis – BG 50/2015

£345.00 exc. VAT

BULK BUY DISCOUNTS AVAILABLE

Micro Analysis Includes

  • Aerobic Colony Count 30C (Also expressed as TVC)
  • Nitrite Reducing Bacteria
  • Sulphite Reducing Bacteria
  • Pseudomonas

And Full Suite of Chemistry analysis, detailed below.

Report comes complete with results, comment and any recommended actions.

You are ordering a sample kit, pre-paid return packet and full laboratory analysis.

Lead Time: Up to 12 working days

We require full sample bottles to be able to perform this test. Refunds will not be offered where minimum sample requirements are not met.
